Comments for Compound (Sliding) Miter Saw 315.23740 Click here to add your own comments

Jun 20, 2012 Sears Miter Saw Blade Removal by: Atomic Gunner Hi John, I just got thru replacing all three motor bearings: 6001, 6002,&6003. and I could not find a motor hold button or slot stop (very sad). On the end of the arbor shaft there is a machined flat that would take 14mm wrench but theres not much room to insert it. You will probably need to use a grinder to make a common thickness 14mm wrench thin enough to fit. This may help though. First the bolt into the arbor is left handed so it must be turned clockwise to remove. second spray some penetrating oil to soak the threads for a day. third the motor fan is quite sturdy and if your carefull as a last resort you can insert a screw driver into the motor side vent port to hold the motor with the fan. I've also had luck removing stuck screws by using a small impact or hammer drill to get a bolt initially free.

Sep 12, 2011 MITER SAW 315.23740 SWITCH SEARCH by: Anonymous A FRIEND OF MINE HAS THIS SAW AND WAS TRYING TO FIND THE SWITCH, WHICH IS A 6 WIRE SYSTEM, PART NUMBER6-612676-00 ON THE PLANS. DOES ANYONE KNOW OF AN ALTERNATIVE SOURCE FOR PARTS LIKE THIS?? ACCORDING TO CRAFTSMAN, THE MANUFACTURER NO LONGER MAKES AND SUPPLIES THIS PART...SO I GUESS ITS TUFF LUCK TO US CRAFTSMAN OWNERS... ANYONE WITH A SOURCE A NOTE BACK WOULD BE GREAT.

Jan 12, 2011 Sears Miter Saw 315.23740 by: Anonymous There is a small button on other side that locks the shaft.

May 04, 2010 Removing bolt by: TRK Sometimes if you will use an impact driver it will overcome the tendaancy of the blade to slip on the shaft. I have one of these I would like to sell if anyone knows someone who trades in old tools. trknust@sbcglobal.net

Jun 07, 2009 change blade by: Elmosr I would use a piece of wood to wedge a tooth of blade against, and use an open end wrench

Jun 06, 2009 change blade by: Elmosr wedge the blade against a piece of wood and just use an open end wrench

Click here to add your own comments Join in and write your own page! It's easy to do. How? Simply click here to return to Vintage Craftsman Tool Photos.
