Comments for Delta Rockwell Radial Arm Saw Average Rating Click here to add your own comments

Apr 20, 2017 Rating 5 years late is better than never by: Anonymous Your serial number indicates it was made at the tupelo division in 1956.

Jun 15, 2012 Rating DELTA ROCKWEL RAS by: YODA THIS SAW LOOKS LIKE MINE. IM RESTORING IT ALSO, SAND BLASTING & THE WHOLE 9 YARDS. iT HAS A ROTATING TORENT AS WELL. I HAVE 4-VINTAGE TABLE SAWS AS WELL INCLUDING A 1949 OR 50 10" TILT TOP TABLE SAW. i LOVE THIS OLD EQUIPMENT . THE NEW STUFF IS CRAP. IM TRYING TO FIND A MANUAL, PARTS BREAKDOWN DIAGRAM & LIST. CAN SOMEONE POST A LOCATION ON HERE? THANKS-KEEP YOUR LIGHT SAVER HANDY

Mar 22, 2012 Rating motor wiring diagram for radial arm saw by: Anonymous I have a Delta Cataloug no 33-564 Ser. No DG 1575,Radial arm saw. When i got the saw the terminal box on top of the motor was a shamble. There is 5 motor leads coming from the motor windings to the terminal box. The Nombers on the leads are T1/T2/T3/T4/and T5. I need a wiring diagrma for connections to on&off switch Capacitor and to the starting relay. Can someone help. Thank you!

Sep 16, 2011 Rating Delta Radial Arm Saw Info by: roger That saw looks just like mine. The serial # is on the mail beam. the catalog # is 33-616. Model looks like a 900. the #'s you put up are the motor #'s. and the # that ends in ccw means counter clockwise rotation! you can still get the original owners manual from porter cable delta tech line. the guy who got them for me was named steve. hope this helps

Click here to add your own comments Join in and write your own page! It's easy to do. How? Simply click here to return to Vintage Delta Tool Photos.
